Grand Harbor^®

A great choice for both new construction or a low-maintenance replacement, the Grand Harbor^® garage doors is a versatile carriage house design that complements a wide range of architectural styles.

3- or 2-Layer Construction

Smooth composite overlays are adhered to a flush 24-gauge steel door

Tough, Layered Coating System

The steel skins of these doors are protected by the use of a tough, layered coating system, which includes a hot-dipped galvanized layer and baked-on primer and top coat.

Door Reinforcement

WindCode^® door reinforcement product available for high wind load applications.

Insulation

Optional 1-5/8" vinyl-backed polystyrene insulation improves energy efficiency. Insulated doors have a 6.3 R-value. (Calculated door section R-value is in accordance with DASMA TDS-163.)

Environmental Assurance

Clopay doors are compliant with environmental laws and regulations. Clopay doors do not contain HFCs. All Clopay doors are compliant with:

• California SB 1013
• Washington HB 1112 – Hydrofluorocarbon Greenhouse Gas Emissions
• Canadian regulations amending the ozone-depleting substances and halocarbon alternatives regulations
• New Jersey A-5583/S-3919 – Greenhouse Gas Bill

A great choice for both new construction or a low-maintenance replacement, the Grand Harbor® garage doors is a versatile carriage house design that complements a wide range of architectural styles.

• Replaceable vinyl bottom weather seal in rust free aluminum retainer helps protect against the elements.
• Grilles are removable for easy cleaning.
• Safe-T-Bracket® - Prevents serious injury that could occur if the bottom bracket were removed with the garage door closed and under tension.
• Rust-Prevention System - Steel skins are protected through a tough, layered coating system, including a hot-dipped galvanized layer, a protective metal oxide pre-treatment and a baked on primer and top coat.

1. Smooth composite overlay
2. Steel
3. 1 5/8" polystyrene insulation (optional)

• Door Designs

• Top Sections

• Colors

• Hardware

Series 1

Design 11

Design 12

Design 13

Series 2

Design 21

Design 22

Series 3

Design 31

Design 36

Series 4

Design 41

Solid Top Sections - Series 1 & Series 2

TOP11

TOP12

TOP13

ARCH1

Solid Top Sections - Series 3 & Series 4

TOP11

ARCH1

WINDOW DESIGNS

Plain Short

SQ22 - GH

Plain Long

REC12

REC14

SQ24

ARCH1

GRVA1

GRLA1

XA24*

XG14*

XG24*

Wrought Iron Short

Wrought Iron Long

Double Top Sections

ARCH3-SOLID-Double Door

ARCH3-WINDOW-Double Door

GRLA3-Windows-Double Door

GRVA3-Windows-Double Door

XA314-Windows-Double Door

XA324-Windows-Double Door

*Faux windows

Standard Colors

Standard White

Almond

Sandtone

Desert Tan

Request Color Samples

*Available on select models. Color Blast® custom paint option available.

Handles

Spade Lift Handles
(included)

Escutcheon Plates

Twisted "T" Handle

Plates

Spade Step Plate

Hinges

Spade Strap Hinge
